The difference between C5 hydrocarbon resin and C9 resin

This is a common topic in the chemical and adhesive industries. Both C5 and C9 resins are hydrocarbon resins produced by polymerizing by-products from petroleum cracking. However, they have significant differences in their raw materials, properties, and applications.

In a nutshell:

• C5 Hydrocarbon Resin: Softer, more flexible, lighter in color, with good compatibility. Primarily used for tackifying and toughening.

• C9 Resin: Harder, more brittle, darker in color, with slight polarity. Primarily used to increase hardness and cohesive strength.

Below is a detailed comparison table and explanation.

Core Differences Comparison Table

Detailed Explanation

1. Different Raw Materials & Structure

• C5 Hydrocarbon Resin: Derived from the "C5 fraction" of petroleum cracking. Main components are aliphatic hydrocarbons and olefins with 5 carbon atoms (e.g., isoprene). Its polymer backbone is aliphatic, making it a non-polar resin.

• C9 Resin: Derived from the "C9 fraction". Main components are aromatic hydrocarbons with 9 carbon atoms (e.g., indene, methylstyrene). Its polymer structure contains many benzene rings, making it a low to medium polarity resin.

This is the root cause of all differences. The chemical structure determines their fundamental properties.

2. Different Physical & Chemical Properties

• Color & Odor: C5 resin is very light in color (water-white) with a low odor, offering better environmental performance. C9 resin is darker with a relatively stronger odor.

• Flexibility vs. Hardness: C5 resin imparts better flexibility, elasticity, and lower permanent deformation to a compound. C9 resin makes a compound harder and more brittle, but with higher cohesive strength (shear resistance).

• Compatibility: This is a key factor in resin selection.

  • C5 resin is perfectly compatible with non-polar materials like natural rubber, polyolefins, EVA, and SBS/SIS thermoplastic elastomers.

  • C9 resin shows better compatibility with materials containing benzene rings or having slightly higher polarity, such as SBR (styrene-butadiene rubber), CR (polychloroprene), and some coating/ink systems.

• Aging Resistance: The aliphatic structure of C5 resin is more stable, generally offering better weather resistance and thermal-oxidative aging resistance than C9 resin. The benzene rings in C9 resin are prone to yellowing and degradation under UV light.

3. Different Application Areas (The Ultimate Basis for Selection)

• Applications of C5 Resin (Focus on "Soft" and "Light"):

  • High-end Hot-Melt & Pressure-Sensitive Adhesives: Used in sanitary napkins, diapers, labels, tapes, etc., where requirements include colorlessness, low odor, softness, and high elasticity.

  • Rubber Products: Used in light-colored or colored tire sidewalls, shoe materials, and rubber parts to provide tack without affecting color or elasticity.

  • Road Marking Paints: Provides high weather resistance and fast drying.

  • Polymer Modification: Acts as a tackifier and plasticizer for elastomers like SBS.

• Applications of C9 Resin (Focus on "Hard" and "Strong"):

  • Tire Rubber: The most important application. Acts as a reinforcing agent and tackifier, improving the strength, wear resistance, and grip of tread compounds.

  • General-Purpose Adhesives & Sealants: Such as construction sealants and contact adhesives, providing initial tack and cohesive strength.

  • Paints & Coatings: Used as a low-cost hard resin to increase film hardness, gloss, and drying speed.

  • Printing Inks: Used in fast-drying inks to improve adhesion.

  •

How to Choose?

Consider the following questions when selecting:

1. What is the base material? (Choose the best compatibility)

2. What properties are needed in the final product? (Soft and elastic, or hard and strong?)

3. Are there requirements for color and odor? (Food packaging and hygiene products require light-colored C5)

4. What is the cost budget? (C9 resin is typically lower in cost than C5 resin)

In recent years, many copolymerized or modified varieties have emerged, such as C5/C9 copolymer resins, which combine the flexibility and light color of C5 with the high tack and fast drying of C9, offering more flexible application possibilities.

Simple Summary:
Think of C5 as a "soft tackifier" for high-end applications requiring elasticity and light color. Think of C9 as a "hard reinforcing agent" for general industrial applications requiring strength and hardness.
